Ultra High Speed: 37 Receipts Per Minute
The Star TSP800II is a revolutionary wide-format POS printer that provides a solution to a number of applications where no POS printer was able to before. From compact web printing to mobile transportation printing as well as producing wide high-quality POS receipts with professional and crisp graphics, the TSP800II is the solution! The TSP800II is the only printer on the market that provides printing on 3" to 4.4" wide paper at an amazing speed. It is the perfect printer for applications that need to print a large amount of information on a receipt. The TSP800II features tear bar and auto-cutter options and a choice of Serial, Parallel, USB, Ethernet, or Wi-Fi interfaces.
Features
- Wide Paper Format (4.4in)
- High Speed 37RPM (180mm/s)
- Prints Receipts, Labels, Tickets, Forms, Barcodes, & Graphics
- Save Paper by Printing A4 Sized Documents on Receipt Paper
- Compact Footprint
- Swappable Interfaces for Easy Future Upgrades
Hardware
- Ultra-Fast 37RPM (180mm/s)
- Wide Area Printing (112mm)
- “Drop-In & Print” Clamshell Design
- Small Footprint
- Receipt, Ticket & Label Paper Available (Up to 0.15mm thick)
- Two Color Print Capable
- Jam Proof, Patented Cutter with Full or Partial Cut
- Swappable Communication Interfaces
- Rear Feed Slot Available for Large Paper Roll
- Horizontal or Vertical Use
Software
- Zoom Raster Driver: A4 to 4 Inch Receipt or 3” to 4 Inch Receipt Logo Utility (Store Logos, Coupons, and Graphics)
- Automatic Second Copy with Raster Driver Memory Switch Configuration / Setup Utility Ethernet / WiFi Interface Setup Utility StarIO SDK
Parts Details:
39443710: TSP847 Receipt Printer with Auto Cutter and Tear Bar Start Up Paper Roll User Manual Ferrite Core (Parallel, USB, Ethernet Models).
Additional Information:
| Color | Grey |
| Fonts & Emulation | - ESC/POS
- Star DP8340
- Star Line Mode
- Star Page Mode
|
| Media Types & Handling | Maximum Label Width: 4.09"
Media Type: Receipt
Media Thickness: 5.91 mil
Maximum Roll Diameter: 3.94"
Media Sensor:
- Reflective Media Sensor
- Paper Low Sensor
- Out of Paper Sensor
- Media Door Open Sensor
|
| Physical Characteristics | Height: 5.8"
Width: 7.1"
Depth: 8.4"
Form Factor: Desktop:
|
| Interfaces/Ports | Parallel Port: Yes |
Cutting Method
| Automatic |
| Memory: | Standard Memory: 2MB
Memory Technology: SRAM
Flash Memory: 16MB |
Input Voltage
| 24 V DC
|
***ONE YEAR LIMITED MANUFACTURERS WARRANTY INCLUDED
