RF IDeas 82 Series card readers are designed for customers seeking to leverage their existing employee ID badges by integrating them into applications beyond door access. This unified platform of products is engineered to work with nearly all proximity, contactless, and magnetic stripe card technologies, providing error-free identification to over a billion cards worldwide.
The WAVE ID 82 Series reader integrates into your software or hardware product through the use of the RF IDeas Universal Software Developer’s Kit (SDK). In contrast to the Enroll readers, the 82 Series use a callable DLL or other direct integration methods rather than keystroking (emulating a keyboard device). These low-cost readers deliver the card ID in a format that applications recognize, offering nearly limitless possibilities for user identification and authentication.
Features:
- Employee familiarity with existing badges
- Supports most ID badge technologies used
- Enhances investment of single badges
- Expands application selections
- Single/common development platform
- No license restrictions
Part Details:
RFIDEAS, WAVE ID SOLO, 82 SERIES, HID PROX, BLACK USB READER
Additional Information:
| Dimensions | 3 3/8” x 2” x 0.6” except for custom Indala, Pyramid |
| Power Supply | USB self-powered; Serial RS232: several power options exist |
| Interface | USB, Serial RS232, Ethernet |
| Indicators | Tri-state LED, beeper |
| Transmit Frequency | Either 125 kHz, 13.56 MHz OR dual 125 kHz & 13.56 MHz (with the pcProx Plus). |
| Ports/Styles | USB, USB Dongle, RS232, PCMCIA, Ethernet, Keyboard, OEM bare board |
