The Elo Touch Solutions 1515L touch monitor is designed, developed, and built to provide a cost-effective touch solution for system integrators and VARs. It packs Elo quality and reliability into an integrated, affordable touch monitor with a footprint smaller than a standard 15” display. This cost and space-saving touch monitor is “designed for touch”— the technology is built into the 1515L from the ground up and not added as an afterthought by altering the original monitor. It includes a stable base, with controls placed on the side rather than the front and locked out for public use. The 1515L can function as a desktop or wall-mounted unit and includes a VESA mounting option. The optional 3-track magnetic stripe reader (MSR), is easily installed by the user, providing an elegant, integrated solution. The display is factory sealed against dirt and dust, and the unit offers a choice of touchscreen technologies: the anti-glare clarity and superior performance of IntelliTouch surface acoustic wave, time-tested AccuTouch five-wire resistive, and IntelliTouch Pro projected capacitive (PCAP) for a multi-touch experience and zero-bezel, seamless design. The Elo 1515L 15” LCD desktop touch monitor provides an affordable product in a convenient, space-saving design that first-time and experienced users can deploy more efficiently, reliably, and more cost-effective than ever before.
Features:
- Optional field-installable 3 stripe MSR
- Sealed touchscreen
- Mounting holes on the base bottom for tabletop security
- Controls on the side, plus lockout function for public use
- Energy-saving LED backlights
- Worldwide agency approvals
- AccuTouch five-wire resistive (activated with fingernails, gloves, credit cards, or any stylus)
- IntelliTouch surface acoustic wave (SAW) for superior image quality (activated with finger or glove)
- IntelliTouch Pro projected capacitive for a sensitive multi-touch performance, and a seamless zero-bezel design
Part Details:
Elo 1515L 15" LCD Touchscreen Monitor - 4:3 - 11.70 ms - 15" (381 mm) Class - AccuTouch - 1024 x 768 - XGA - 16.7 Million Colors - 700:1 - 250 cd/m² - LED Backlight - USB - VGA, Dark Gray - MPR II, China RoHS
Additional Information:
| Display Type | Active matrix TFT LCD with LED backlighting |
| Display Size | 15.0” diagonal |
| Useful Screen Area | Horizontal: 12.0” (304mm); Vertical: 9.0” (228mm) |
| Monitor Dimensions | Width: 13.8” (350mm) Height: 12.2” (310mm) Depth: 6.9” (175mm) |
| Colors | 16.7 million |
| Response Time (total–typical) | 11.7 msec |
| Mounting Options | Removable base, 75mm VESA mount; threaded-through mounting holes under base |
| Touch Interface | Serial and USB |
***ONE YEAR LIMITED MANUFACTURERS WARRANTY INCLUDED
