Edge-to-Edge Design with Integrated 10-Touch
Offering the same seamless design that spans the entire ELO 02-Series lineup the 0702L is only half an inch thin and tailored for ease of integration. Designed to thrive in customer-facing installations in point of sale, brand loyalty, point-of-information, signage, and hospitality applications. The slim footprint of the 0702L touchscreen monitor makes it the ideal solution for industrial kitchens. Using DisplayLink technology, the 0702L provides a single-cable solution that combines power, video, and touch signals into one USN connection.
Part Details:
E796382: 7-inch wide LCD Desktop, 800 x 480, Projected Capacitive 10-touch, Anti-Glare, Zero-Bezel, DisplayLink Input, Black Touchmonitor, Micro USB Y-cable, Quick Install Guide
Additional Information:
| Color | Black |
| Diagonal size | 7 inches |
| Mounting OPTIONS | VESA 75mm x 75mm |
| I/O Ports | 1 x Micro USB (DisplayLink input for touch, video & power) |
| Active Touch Area | 6.07" 3.38" |
| LCD Technology | Active Matrix TFT LCD |
| Touch Technology | TouchPro PCAP |
| Number of Touches | 10 Touches |
| Aspect Ratio | 5:3 |
| Contrast Ratio (Typical) | 500:1 |
| Native Resolution | 800 x 480 |
| Preset Video Timings | 800 x 480 60 Hz |
| Brightness (typical) | Panel: 500 nits; with TouchPro PCAP: 430 nits |
| Response Time (Tr + Tf) (typical) | 25 msec |
| Power | Input Connector: Micro USB
Input signal specifications: 5 V ±5%
Power Consumption (Typical):
- On: 3.7 W
- Sleep: 0.9 W
- Off: 1.9 W
|
| Dimensions (HxWxD) | 4.61" x 7.11" x 0.7" |
***ONE YEAR LIMITED MANUFACTURERS WARRANTY INCLUDED
